Azure SQL Server VNet Integrated using Bicep

I have a terrible memory so this blog post is mainly to remind me how to VNet Integrate Azure SQL.

The code below is creating an Azure SQL Server and VNet integrating it – the VirtualNetworkRule is the key part and the following is how to go about it.

I use this existing Bicep repo for all of the Bicep that I write – https://github.com/Azure/ResourceModules/

@description('Deploy an Azure SQL Server')
module createAzureSQL 'modules/azuresql_modules/deploy.bicep' = if (deployAzureSQL) {
  scope: resourceGroup(dataTierRg)
  name: azureSQLServerName
  params: {
    name: azureSQLServerName
    location: sqllocation
    administratorLogin: azureSQLServerAdminLogin
    administratorLoginPassword: azureSQLAdminPassword
    tags: tags
    virtualNetworkRules: [
      {
        name: 'vnet-rule-${azureSQLServerName}'
        serverName: azureSQLServerName
        ignoreMissingVnetServiceEndpoint: false
        virtualNetworkSubnetId: '/subscriptions/${subscriptionID}/resourceGroups/${appTierRg}/providers/Microsoft.Network/virtualNetworks/${appVNetName}/subnets/dataSubNet'
      }
    ]
  }
  dependsOn: [
    newRG
    createAppVNet
  ]
}

To get this to work you should also add a service endpoint into your subnet like the following:-

@description('An array of the subnets for the Application VNet.')
var appSubnets = {
  shared: [

    {
      name: 'appSubnet'
      addressPrefix: '172.16.0.0/24'
      delegations: [
        {
          name: 'delegation'
          properties: {
            serviceName: 'Microsoft.Web/serverfarms'
          }
        }
      ]
    }
    {
      name: 'dataSubNet'
      addressPrefix: '172.16.1.0/24'
      serviceEndpoints: [
        {
          service: 'Microsoft.Sql'
        }
      ]
    }
  ]
}

Let me know if you found this example useful.
